Instrumentation Union Fittings

Name: Instrumentation Union Fittings
Brand: ROMEX TUBES AND FITTINGS
Price: 200 INR
Availability: InStock

Price 200 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Instrumentation Union Fittings Specification

Material Composition %
Cr 18-20%, Ni 8-12%, Mo 2-3% (for SS316)

Heat Resistance
Yes

Tensile Strength
515 MPa min (for SS304)

Hardness
160-190 HB

Diameter
1/8 to 2 OD

Corrosion Resistant
Yes

Size
Available in multiple sizes (1/8 to 2 OD)

Recyclable
Yes

Product Form
Union fitting

Coating Type
Uncoated / Natural

Product Name
Instrumentation Union Fittings

Steel Type
Stainless Steel

Steel Product Type
Fittings

Grade
SS304, SS316, SS316L (available variants)

Thickness
Standard fitting wall thickness as per instrumentation standards

Shape
Union (Hexagonal/Barrel type)

Steel Standard
ASTM A182 / A276

Surface
Polished

Composition
Stainless Steel composition (Cr, Ni, Mo)

Application
Industrial instrumentation tubing and piping systems

Dimension (L*W*H)
Varies as per size, typically compact union sizes

Weight
Dependent on size, generally lightweight

Color
Metallic Silver

Material Grade
SS304, SS316

Finish Type
Bright/Polished

Usage
Pipe/tube connection in process instrumentation lines

Marking
Size, grade, manufacturer embossed on body

Application Segment
Chemical, Petrochemical, Oil & Gas, Power Plants, Pharmaceuticals

Media Conveyed
Liquid, Gas, Steam

Working Pressure
Up to 6000 psi (varies by size & material)

Packaging
Export worthy, polybag packed

Installation
Easy installation, requires no welding

Thread Type
NPT / BSP / BSPT / Metric as required

Temperature Range
-50C to 400C

Connection Type
Double ferrule / Compression

Sealing Type
Metal-to-metal leak-proof seal

Resistance Properties
High corrosion and oxidation resistance

Instrumentation Union Fittings Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
500 Pieces Per Month

Delivery Time
3 Days

Instrumentation Union Fittings About

Discover the impeccable value of our Instrumentation Union Fittings, renowned for their grandiose reliability across demanding industrial sectors. In demand for applications in chemical, petrochemical, oil & gas, and power plants, these fittings are crafted from premium SS304 and SS316, ensuring high corrosion and oxidation resistance. Designed with a double ferrule compression connection and a metal-to-metal leak-proof seal, they boast up to 6000 psi working pressure. The easy, welding-free installation enhances system integrity, making them the preferred choice for professionals seeking optimal performance and safety. Buy now for unmatched durability and precision engineering.

Competitive Advantages and Commercial Uses

Our Instrumentation Union Fittings are engineered for performance and dependability, featuring impeccable sealing technology and robust resistance properties. Their value lies in effortless installation, requiring no welding and minimizing downtime. These renowned union fittings are suitable for diverse commercial uses, including process lines in pharmaceuticals, power plants, oil & gas, and chemical industries. Designed for compactness and lightweight handling, they are versatile for both new projects and maintenance upgrades, maximizing operational efficiency and process reliability.

Markets, Export Packaging, and Domestic Reach

Instrumentation Union Fittings are highly sought after in global markets, including Asia-Pacific, Europe, and the Middle East, with frequent proposals amounting to sizable international orders. Each batch is polybag packed and dispatched in export-worthy cartons, reducing freight risks during shipping. On the domestic front, these fittings securely serve buyers across India, benefitting from swift logistics and dependable supply chains. Our comprehensive packaging and timely dispatch ensure quality fittings reach you wherever your operations may be.

FAQ's of Instrumentation Union Fittings:

Q: How do Instrumentation Union Fittings ensure leak-proof sealing?

A: These fittings utilize a metal-to-metal seal with double ferrule compression, delivering a reliable, leak-proof connection for high-pressure and high-temperature applications.

Q: What are the installation requirements for these union fittings?

A: No welding is necessary; installation involves simply securing the compression fitting onto the tubing, making the process quick, convenient, and safe for industrial environments.

Q: Where are Instrumentation Union Fittings commonly used?

A: They are widely used in chemical, petrochemical, oil & gas, power plant, and pharmaceutical sectors to connect instrumentation piping and tubing lines conveying liquids, gases, or steam.

Q: What benefits do these fittings offer for industrial projects?

A: Key benefits include high resistance to corrosion and oxidation, ease of installation, robust pressure and temperature ratings, and compatibility with various thread types such as NPT, BSP, BSPT, and metric.

Q: How are Instrumentation Union Fittings packaged for export and domestic delivery?

A: Fittings are individually polybag packed and placed in sturdy export cartons, protecting them during freight and handling for both domestic and international shipments.
